Modern Farmhouse Style Carriage House Plan

Elm Springs - 30198

Sq Ft
57' 8"
49' 5"

Floor Plan Images

Main Level

Elm Springs

Second Level

Elm Springs

Plan Description

This charming modern farmhouse style carriage house plan boasts 1870 sq ft of living space, spread across two bedrooms and three bathrooms. The exterior of the home is accented with classic farmhouse elements, such as board and batten siding and a gabled roof, while the interior is filled with modern touches, including an open floor plan and high-end finishes.

The main level of the home features an RV garage, rec area, 4 seasons room, and a shop area. The upper level includes a spacious great room, a gourmet kitchen with a large center island, and a formal dining area.

The upper level also houses the two bedrooms, including a luxurious master suite with a private bathroom and walk-in closet. A third bathroom is located on the main level, just off the garage, making it convenient for anyone working in the three-bay garage or coming in from the outdoors.

This beautiful carriage house plan is the perfect combination of classic and modern, making it the perfect place to call home.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Bedrooms 2
Bathrooms 3
Garage Bays 3
Square Footage
Main Level 537 Sq. Ft.
Second Level 1333 Sq. Ft.
Covered Area 188 Sq. Ft.
Garage 1584 Sq. Ft.
Total Finished Area 1870 Sq. Ft.
Exterior Dimensions
Width 57 ' 8"
Depth 49 ' 5"
Ridge Height
Calculated from main floor line
30 ' 7"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Exterior Wall Construction
Roof Pitches
Primary 5/12, Secondary 10/12, 3/12
Main Wall Height
Second Wall Height

What is included in a set of house plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell.

Our blueprints include:

Cover Sheet: Shows the front elevation often times in a 3D color rendering and typical notes and requirements.
AHP Plan Cover Sheet
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
AHP Front and Rear Elevations
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
AHP Example Foundation Plan
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
AHP Example Floor Plan
Roof Plan
AHP Example Roof Plan
Typical Wall Section, Stair Section, Cabinets
AHP Example Sections
