Modern Style 1 Car Garage Plan with Shop and Covered Patio

Kimmons - 29362

153
Sq Ft
0
Beds
0
Baths
1
Bays
28' 8"
Wide
30' 0"
Deep

Floor Plan Images

Main Level

Modern Style Specialty Garage Plan | Kimmons

Plan Description

The Kimmons is a modern rustic style garage with a workshop. It's a perfect hobby garage with 10'x10' door and plenty of space to store and work on boats, vintage cars, and more! The workshop space is designed for smaller projects with cabinets and counter space. The room features a boxed out corner window which allows for additional counter space and modern appeal.

This plan is designed to be functional and beautiful - a garage one could spend all day in! The garage ceiling slopes with the roof, with a bank of clerestory windows to bring in lots of light. There is a secondary garage door to really open up the space to let in some fresh air, to work outside when you just need some extra space, or even to relax or throw a party under the covered patio.

The workshop walls are 9'. The garage walls start at 12' and slope up to a maximum wall height of about 17'-4".

As always, we can modify any of our garage plans with our in house home plan alteration department. Contact us today at  (844) 675-9638  or info@advancedhouseplans.com

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Layout
Garage Bays 1
Square Footage
Main Level 153 Sq. Ft.
Garage 480 Sq. Ft.
Total Finished Area 153 Sq. Ft.
Exterior Dimensions
Width 28' 8"
Depth 30' 0"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Slab
Exterior Wall Construction
2x4
Roof Pitches
4/12 Primary
Main Wall Height
9'

What is included in a set of house plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell. Depending on the home designer there might be more home building information provided.

Our blueprints include:

Cover Sheet: Shows the front elevation often times in a 3D color rendering and typical notes and requirements.
AHP Plan Cover Sheet
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
AHP Front and Rear Elevations
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
AHP Example Foundation Plan
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
AHP Example Floor Plan
Roof Plan
AHP Example Roof Plan
Typical Wall Section, Stair Section, Cabinets
AHP Example Sections
If you have any additional questions about what you are getting in a plan set, contact us today at sales@advancedhouseplans.com
Buy this plan for only
$500

If you find this plan cheaper on any other site, we will match the price guaranteed.
