29527 | Southdale


Southdale Rendering
Want to make changes to this plan?

1 1/2 Story Craftsman House Plan

Southdale - 29527

Sq Ft
91' 0"
110' 0"

Floor Plan Images

Main Level

1 1/2 Story Craftsman House Plan | Southdale

Second Level

1 1/2 Story Craftsman House Plan | Southdale

Plan Description

Classic Craftsman accents enhance the curb appeal of this remarkable 1.5-story house plan.  As you enter through the grand entry, guests are treated to stunning views of a 2 story cathedral ceiling in the great room with a fireplace. The great room flows into a large open kitchen and dining room with a cathedral ceiling.  The angled master suite enjoys seclusion from the main floor’s living areas. Its bath area includes his and her vanities with a massive walk in closet and a walk in shower. This home is perfect for entertaining large groups with its huge deck area.

On the upper level, you will find a study which leads to storage that spans above a 3 car garage. Next to the study is bedroom 4 which has its own bathroom and walk-in closet. As you walk across the catwalk you will have excellent views below to the great room and grand entrance on the way to bedroom 2 and 3. Bedroom 2 and 3 share a bathroom and each has a walk-in closet.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Bedrooms 4
Bathrooms 4
Garage Bays 4
Square Footage
Main Level 3290 Sq. Ft.
Second Level 1620 Sq. Ft.
Garage 1454 Sq. Ft.
Total Finished Area 4910 Sq. Ft.
Exterior Dimensions
Width 91 ' 0"
Depth 110 ' 0"
Ridge Height
Calculated from main floor line
35 ' 0"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Exterior Wall Construction
Roof Pitches
12/12 S-S, 8/12 F-B
Foundation Wall Height
Main Wall Height
Second Wall Height

What is included in a set of house plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell.

Our blueprints include:

Cover Sheet: Shows the front elevation often times in a 3D color rendering and typical notes and requirements.
AHP Plan Cover Sheet
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
AHP Front and Rear Elevations
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
AHP Example Foundation Plan
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
AHP Example Floor Plan
Roof Plan
AHP Example Roof Plan
Typical Wall Section, Stair Section, Cabinets
AHP Example Sections
If you have any additional questions about what you are getting in a plan set, contact us today at [email protected]
