Craftsman Style ADU House Plan

Madeline - 29508

Sq Ft
24' 0"
30' 0"

Floor Plan Images

Main Level

Cottage Style Cabin Plan | Madeline

Second Level

Cottage Style Cabin Plan | Madeline

Plan Description

The Madeline, with it's charming craftsman style and great curb appeal, is a great home for a fun getaway. The exterior is enhanced by a covered deck with 4 columns that give this cabin a classic craftsman look. Inside you'll find a large great room that is warmed by a fireplace and a full kitchen complete with an island and breakfast bar.   The master bedroom, located on the main floor, has a walk-in closet. In the great room you will find a ladder that leads to a loft that can be used as a second bedroom. The cathedral ceilings make this cabin feel even larger than it is.

As always any Advanced House Plans home plan can be customized to fit your needs with our alteration department. Whether you need to add another garage stall, change the front elevation, stretch the home larger or just make the home plan more affordable for your budget we can do that and more for you at AHP.

Unless you purchase an unlimited use license or a multi-use license you may only build one home from a set of plans. Plans cannot be re-sold.

Construction Specs

Bedrooms 1
Bathrooms 1
Square Footage
Main Level 576 Sq. Ft.
Second Level 146 Sq. Ft.
Total Finished Area 722 Sq. Ft.
Exterior Dimensions
Width 24 ' 0"
Depth 30 ' 0"
Ridge Height
Calculated from main floor line
21 ' 0"
Default Construction Stats
Stats are unique to the individual plan.
Foundation Type
Exterior Wall Construction
Roof Pitches
Primary 12/12, Secondary 4/12
Main Wall Height
Second Wall Height

What is included in a set of house plans?

Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell.

Our blueprints include:

Cover Sheet: Shows the front elevation often times in a 3D color rendering and typical notes and requirements.
AHP Plan Cover Sheet
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
AHP Front and Rear Elevations
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
AHP Example Foundation Plan
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
AHP Example Floor Plan
Roof Plan
AHP Example Roof Plan
Typical Wall Section, Stair Section, Cabinets
AHP Example Sections
If you have any additional questions about what you are getting in a plan set, contact us today at [email protected]
