Modern Dog House Plan | Elm Creek
Floor Plan Images
Plan Description
The Elm Creek dog house is a cozy plan that will look great in anybody's backyard. The large dog run gives your furry friend a great space to be outdoors while still safely locked up. A person door is located on the side of this plan so your dog food and toys can be stored inside without allowing your dog to access them on their own. A chain-link fence separates the dog's living quarters from the rest of the dog house.
Construction Specifications
| Basic Layout Information | |
| Bedrooms | 0 |
| Bathrooms | 0 |
| Garage Bays | 0 |
| Square Footage Breakdown | |
| Main Level | 96 Sq Ft |
| Total Finished Area | 96 Sq Ft |
| Covered Areas (patios, porches, decks, etc) | 64 Sq Ft |
| Exterior Dimensions | |
| Width | 20' 0" |
| Depth | 8' 0" |
| Default Construction Stats | |
| Default Foundation Type | Slab |
| Default Exterior Wall Construction | 2x4 |
| Roof Pitches | 2/12 Primary |
| Main Level Ceiling Height | 9' |
What's Included in a Plan Set?
Each set of home plans that we offer will provide you with the necessary information to build the home. There may be some adjustments necessary to the home plans or garage plans in order to comply with your state or county building codes. The following list shows what is included within each set of home plans that we sell.
Our blueprints include:
Cover Sheet: Shows the front elevation often times in a 3D color rendering and typical notes and requirements.
Exterior Elevations: Shows the front, rear and sides of the home including exterior materials, details and measurements
Foundation Plans: will include a basement, crawlspace or slab depending on what is available for that home plan. (Please refer to the home plan's details sheet to see what foundation options are available for a specific home plan.) The foundation plan details the layout and construction of the foundation.
Floor Plans: Shows the placement of walls and the dimensions for rooms, doors, windows, stairways, etc. for each floor.
Electrical Plans: Shows the location of outlets, fixtures and switches. They are shown as a separate sheet to make the floor plans more legible.
Roof Plan
Typical Wall Section, Stair Section, Cabinets
If you have any additional questions about what you are getting in a plan set, contact us today.
Upgrade Your Plan With Add-ons
Note: Add-ons may result in a longer turn-around time.
Note: The material list is for estimation purposes only.
